• AMD A10-5800B with Radeon HD 7660D Graphics (3.8 GHz, 4MB L2 cache, 100 W)
• AMD A8-5500B with Radeon HD 7560D Graphics (3.2 GHz, 4MB L2 cache, 65 W)

• AMD A6-5400B with Radeon HD 7540D Graphics (3.6 GHz, 1MB L2 cache, 65 W)
• AMD A4-5300B with Radeon HD 7480D Graphics (3.4 GHz, 1MB L2 cache, 65 W)

• AMD Radeon HD 6350 (512MB) PCIe x16 (includes a DMS-59 to Dual VGA Y cable)
• AMD Radeon HD 7450 (1GB) PCIe x16 (includes a DVI to VGA adapter cable)
• NVIDIA NVS 300 (512MB) PCIe x16 (includes a DMS-59 to Dual VGA Y cable)
• NVIDIA NVS 310 (512MB) PCIe x16
• NVIDIA GeForce GT 630 PCIe x 16

• DisplayPort to DVI-D adapter
• DisplayPort to HDMI adapter
• DisplayPort to VGA adapter
• DisplayPort cable
• HP DVI cable kit
• HP DVI to VGA adapter

• 250GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV, 3.5 inch
• 500GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV, 3.5 inch
• 1TB, 7200 rpm, SATA 6.0 Gb/s, SMART IV, 3.5 inch

• 500GB, SATA, 3.5 inch

• 256GB, SATA, 3.5 inch

• 120GB, SATA (with 3.5-inch adapter)
• 128GB, SATA (with 3.5-inch adapter)

• DVD-ROM
• Super Multi Drive
• Blu-ray BDXL SATA Drive

• HP 22-in-1

• DDR3 non-ECC
• Up to 1600 MT/s

• Broadcom NetXtreme Gigabit Ethernet BCM 5761 (integrated)
• Broadcom NetXtreme Gigabit Ethernet Plus PCIe NIC (optional)

• High Definition Audio with Realtek ALC221 codec (all ports are stereo)
• Microphone and headphone front ports (3.5 mm)
• Line-out and Line-In rear ports (3.5 mm)
• Multi-streaming capable
• Internal speaker (standard)
• Thin USB power speakers (optional)

• PS/2 keyboard
• USB keyboard
• USB Smart Card (CCID) keyboard
• USB and PS/2 washable keyboard
• Wireless keyboard and mouse combo
• Wireless keyboard and dongle (Brazil)

• PS/2 optical mouse
• USB optical mouse
• USB laser mouse
• USB and PS/2 washable mouse
• Wireless laser mouse (Brazil)

• Trusted Platform Module (TPM) 1.2
• SATA port disablement (via BIOS)
• Drive lock
• Serial, parallel, USB enable/disable (via BIOS)
• Optional USB port disable at factory (user configurable via BIOS)
• Removable media write/boot control
• Power-On password (via BIOS)
• Setup password (via BIOS)
• HP Solenoid Hood Lock/Sensor
• Support for chassis padlocks and cable lock devices

• 240 W, active PFC, 90% high efficiency
• 240 W active PFC, standard efficiency

• Four USB 3.0 (rear)
• Four USB 2.0 (front)
• Two USB 2.0 (rear)
• One serial RS-232 compatible
• Two PS/2 (color-coded support for keyboard (purple) and mouse (green)
• One VGA
• One DisplayPort
• One microphone and headphone (front)
• One Audio-in and Audio-out (rear)
• One RJ-45 (accesses the integrated network interface controller)

• One serial RS-232 compatible
• One parallel
• One eSATA

• PCI (5 V):
  One each
  4.2-inch full height
  6.6-inch length
  25-W maximum power

• PCI Express x1 (2.0):
  One each
  4.2-inch full height
  6.6-inch length
  10-W maximum power

• PCI Express x16 (3.0 – primary) (secondary slot physically x16 wired as x4):
  Two each
  4.2-inch full height
  6.6-inch length
  75-W maximum power

• One 3.5-inch external (For Media Card Reader unless used for secondary data drive)
• Two 5.25-inch external
  • 8.19-inch depth
• Two 3.5-inch internal HDD

NOTE:

1: For systems configured with more than 3GB of memory and a 32-bit operating system, all memory may not be available due to system resource requirements. Addressing memory above 4GB requires a 64-bit operating system. Memory modules support data transfer rates up to 1600 MT/s; actual data rate is determined by the system’s configured processor. See processor specifications for supported memory data rate.

2: The front microphone port is re-taskable as a Line-in, Microphone-in or Headphone-out port. Rear audio input ports are re-taskable as a Line-in or Microphone-in port. External speakers must be powered externally. Multi-streaming can be enabled in the Realtek control panel to allow independent audio streams to be sent to/from the front and rear jacks. This allows for different audio applications to use separate audio ports on the system. For example, the front jacks could be used with a headset for a communications application while the rear jacks are being used with external speakers and a multimedia application.

NOTE:

1: High efficiency power supply is a requirement for ENERGY STAR qualification in conjunction with a select range of processors and modules.

NOTE:

1: Other resolutions may also work, but have not been validated.

NOTE:

Other resolutions may be available but are not recommended as they may not have been tested and qualified by HP.

60-R denotes reduced blanking timings are used on single link DVI connections and may be sued with other digital connections.

NOTE:

1: Only supported with a Display Port monitor connection.

Only supported when using a dual link DVI or DP monitor connection.

60-R denotes reduced blanking timings are used on single link DVI connections and may be sued with other digital connections.

Other resolutions may be available but are not recommended as they may not have been tested and qualified by HP.

• Directx 10.1
• OpenGL 3.3
• CUDA
• DirectCompute

• Full screen, full frame video playback of HDTV, Blu-ray and DVD content
• Inbuilt video decoder for multiple video formats including MPEG2, VC-1, WMV9, H.264, and MVC
• Capable of decoding dual Video Streams at HD (1080p) resolutions
• Hardware color-space conversion (YUV 4:2:2 and 4:2:0)
• High-Quality in-built Filtering/Scaling
• Stereo & HD Audio (LPCM 7.1) support for HDMI outputs (HDMI via optional DVI-HDMI dongles) with the DMS-59 to DisplayPort adapter

NOTE:

1: 60-R denotes reduced blanking timings are used on single link DVI connections and may be used with other digital connections.
